The APVCAM4 is a universal multi camera switch interface that enables multiple cameras to be connected to an aftermarket AV headunit or display. It features four RCA camera inputs (front, rear, left and right) and one RCA video output which connects into the video input on the aftermarket display. The inputs are voltage triggered determined by driver behaviour, with the rear camera input automatically activated when the vehicle is shifted into reverse and side inputs prompted by the turn signals. The APVCAM4 is the perfect interface when multiple cameras are being installed on a vehicle.

• Allows up to four cameras to connect to a single display
• Four RCA camera inputs (front, rear, left and right)
• Single RCA output for connecting to compatible aftermarket AV headunit or display
• Connects directly to analogue turn signal circuit with flash eliminating signal buffer for uninterrupted side camera activation
• Priority override for reverse camera signal
• Provides reverse camera output trigger for aftermarket radios
